PERFORMANCE
Processor AMD Ryzen™ 5 220 (6C / 12T, 3.2 / 4.9GHz, 6MB L2 / 16MB L3)
AI PC Category Non-AI PC
NPU None
Graphics Integrated AMD Radeon™ 740M Graphics
Chipset AMD SoC Platform
Memory 1x 8GB SODIMM DDR5-5600
Memory Slots Two DDR5 SODIMM slots, dual-channel capable
Max Memory Up to 64GB DDR5-5600
Storage 512GB SSD M.2 2280 PCIe® 4.0×4 NVMe® Opal 2.0
Max Storage Support “Up to three drives, 1x 3.5″” HDD + 2x M.2 SSD
• 3.5″” HDD up to 2TB
• M.2 SSD up to 1TB each, To in
Card Reader No Card Reader
Optical None
Audio Chip High Definition (HD) Audio, Realtek® ALC623 codec
Speakers 1Wx1
Power Supply 200W 90%
DESIGN
Keyboard USB, Calliope, Black, Spanish (LA)
Mouse USB Calliope Mouse, Black
Expansion Slots One PCIe® 4.0 x16, low-profile, length ? 155mm, height ? 70mm, Three M.2 slots (one for WLAN, two for SS
Case Color Raven Black
Stand None
Pen Pen Not Supported
Form Factor SFF (8.2L)
Dimensions (WxDxH) 89 x 274.8 x 336 mm (3.5 x
