PERFORMANCE
Processor Intel Core i7-14700, 20C (8P + 12E) / 28T, Max Turbo up to 5.4GHz, P-core 2.1 / 5.3GHz, E-core 1.5 / 4.2GHz, 3
Graphics Integrated Intel UHD Graphics 770
Chipset Intel B760 Chipset
Memory 1x 16GB UDIMM DDR5-5600
Memory Slots Two DDR5 UDIMM slots, dual-channel capable
Max Memory Up to 64GB DDR5-5600
Storage 512GB SSD M.2 2280 PCIe 4.0×4 NVMe Opal 2.0
Max Storage Support “Up to two drives, 1x 3.5″” HDD + 1x M.2 SSD
• 3.5″” HDD up to 2TB
• M.2 SSD up to 1TB
For installin
Card Reader None
Optical 9.0mm DVD±RW
Audio Chip High Definition (HD) Audio, Realtek ALC623-CG codec
Speakers 1Wx1
Power Supply 260W 90%
DESIGN
Keyboard USB Calliope Keyboard, Black, Spanish (LA)
Mouse USB Calliope Mouse, Black
Expansion Slots “One PCIe 3.0 x16, low-profile, length = 155mm, height = 70mm
One PCIe 3.0 x1, low-profile, length = 155
Case Color Chassis: Black, Bezel: Grey
Stand None
Pen Pen Not Supported
Form Factor SFF (8.2L)
Dimensions (WxD
