PU
Intel® Celeron® Dual-Core J4005 SoC onboard Processors
Memory
2 x U-DIMM, Max. 8GB, DDR4 2400/2133 MHz Non-ECC, Un-buffered Memory *1
Dual Channel Memory Architecture
* Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists).
Graphic
Integrated Graphics Processor
Multi-VGA output support : HDMI/RGB/LVDS ports
– Supports HDMI with max. resolution 4096 x 2304 @ 24 Hz
– Supports LVDS with max. resolution 1920 x 1200 @ 60 Hz
– Supports RGB with max. resolution 1920 x 1200 @ 60 Hz
Maximum shared memory of 512 MB (for iGPU exclusively)
Supports up to 3 displays simultaneously
Storage
1 x M.2 Socket 3, , with M Key, type 2260/2280 storage devices support (PCIE mode)
2 x SATA 6Gb/s port(s),
LAN
Realtek® RTL8111H, 1 x Gigabit LAN Controller(s)
Audio
Realtek® ALC887-VD2 8-Channel High Definition Audio CODEC *2
– Supports : Jack-detection, Front Panel Jack-retasking
USB Ports
Built-in Controller :
4 x USB 3.1 Gen 1 port(s) (2
